RadExpand 5 Plus Electric Folding Bike

RadExpand 5 Plus
Power. Portability. Plus Everything You Need.

The RadExpand 5 Plus is a foldable, fat tire electric bike built for adventure, urban utility, and comfort. With an upgraded 720Wh battery, hydraulic disc brakes, and a smooth torque sensor, this ebike delivers a natural ride feel and serious performance—all in a compact, foldable frame.

🔋 Electronics & Performance

• Motor: 750W rear hub motor with 64Nm torque (Class 1 & 2 switchable)

• Battery: 48V, 15Ah (720Wh) with Samsung or LG cells

• Range: 20–60 miles per charge

• Pedal Assist: 5 levels + 0 assist, with torque sensor for smooth, responsive ride

• Throttle: Half-twist throttle on demand

• Display: Custom Rad color display with USB-C port

• Lights: Auto-on 200-lumen front headlight, integrated rear brake + turn signals

• Charger: 2 Amp smart charger (100V–240V compatible)

• UL Certified: UL 2849 (e-bike) & UL 2271 (battery)

🛠 Components & Comfort

• Fork: Exsho STRONG-C hydraulic suspension fork (50mm travel)

• Brakes: Gemma hydraulic disc brakes w/ 180mm rotors

• Drivetrain: Shimano 7-speed w/ 14–32T freewheel

• Tires: 20" x 4.0" CST BFT with puncture-resistant liner + reflective strip

• Frame: Lightweight aluminum, fully foldable

• Saddle: Comfort touring seat with anatomical cut-out

• Fenders & Rear Rack: Full-coverage fenders + integrated 59 lb-capacity rack

📏 Rider Fit & Features

• Handlebars: 680mm wide aluminum, folding stem riser

• Grips: Ergonomic rubber

• Kickstand: Side-mounted, adjustable

• Pedals: Folding platform pedals

• Seatpost: 390mm, 27.2mm diameter

• Total Payload Capacity: ~275+ lbs recommended

From city streets to campground trails, the RadExpand 5 Plus is built to adapt. Its compact foldability makes it easy to store, while upgraded electronics and comfort components make every ride effortless and fun.
